ASAM MCD 3MC Window
The window contains the following components:

The ASAM MCD 3MC window contains the following menus:
This menu contains the following functions:
Clear Window
Clears the contents in the display area of the ASAM MCD 3MC window.
Exit
Closes the ASAM MCD 3MC window.
Note |
Before closing the ASAM MCD 3MC Interface, make sure that communication between INCA and the testbed is finished. |
This menu contains the following functions:
Copy
Copies the marked text to the clipboard.
Select All
Marks the entire text in the display area of the ASAM MCD 3MC window.
This menu contains the following functions:
Toolbar
Shows or hides the toolbar.
Status Bar
Shows or hides the status bar.
Logging
Specifies data to be logged and where:
| Activity log information is displayed on the screen. |
| Activity log information is written to the log file. The file is not automatically deleted; new log data is appended if the file already exists. |
| Interface log information is displayed on the screen. The file is not automatically deleted; new log data is appended if the file already exists. |
| Interface log information is written to the log file. The file is not automatically deleted; new log data is appended if the file already exists. |
| Logs all error messages during an ASAM MCD 3MC session. |
Errors and Client Commands | Logs all error messages and ASAM MCD 3MC commands with parameters sent from the testbed. |
Errors, Client Commands and Server Responses | Logs all error messages, all ASAM MCD 3MC commands with parameters sent from the testbed, as well as all responses, events and error messages sent to the testbed. |
| Logs all write accesses to calibration data during an ASAM MCD 3MC session. |
| Logs all read accesses to calibration data during an ASAM MCD 3MC session. |
This menu contains the following functions:
Options
Opens the Options dialog box in which you can define settings for the ASAM MCD 3MC Interface.
Export Current Options
Opens a dialog box for specifying an INI file to which the current settings of the ASAM MCD 3MC Interface are exported.
Always on Top
Keeps the ASAM MCD 3MC window permanently in front of other windows.
This menu contains the following functions:
Help
Opens the INCA help.
Help on Current Window
Opens the help of the ASAM MCD 3MC Interface.
About
Opens an information window on the ASAM MCD 3MC Interface.
The toolbar contains the following icons:
| Clears the contents in the display area of the ASAM MCD 3MC window. |
| Copies the marked text to the clipboard. |
| Activity log information is displayed on the screen. |
| Activity log information is written to the log file. |
| Interface log information is displayed on the screen. |
| Interface log information is written to the log file. |
| Logs all error messages during an ASAM MCD 3MC session. |
| Logs all error messages and ASAM MCD 3MC commands with parameters sent from the testbed. |
| Logs all error messages, all ASAM MCD 3MC commands with parameters sent from the testbed, as well as all responses, events and error messages sent to the testbed. |
| Logs all write accesses to calibration data during an ASAM MCD 3MC session. |
| Logs all read accesses to calibration data during an ASAM MCD 3MC session. |
| Opens the Options dialog box in which you can define settings for the ASAM MCD 3MC Interface. |
| Keeps the ASAM MCD 3MC window permanently in front of other windows. |
| Opens an information window on the ASAM MCD 3MC Interface. |
Activity to Screen
Activity to File
Interface to Screen
Interface to File
Errors

Calibration Write
Access
Calibration Read
Access
