CBE260 Cable
Usage
Gigabit Ethernet and Power Connection cable for FETK (reused by FETK). Lemo connectors on both sides compliant to IP65. 3 m length.
The CBAE260 cable is a Gigabit Ethernet cable to connect an ETAS ES device with an FETK or another ES device. The cable supports power propagation.
Connectors
|
Connector |
Color |
Target |
|---|---|---|
|
CON1 |
Pastel purple |
ES8xx Downlink |
|
CON2 |
Blue purple |
ES8xx Uplink, FETK |
Temperature Range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +120 °C |
Order Information
|
Product |
Length |
Order Number |
|
CBE260.1-3 |
3 m |
F 00K 109 446 |
|
CBE260.1-5 |
5 m |
F 00K 111 001 |
|
CBE260.1-8 |
8 m |
F 00K 109 447 |
