CBAM305 Cable
The CBAM305.1 FETK cable (reused by FETK) is a 1 GBit/s Ethernet cable adapter with external power supply for FETKs.
Pre-assembled into PG9 screwing, shield connected to the screwing. It is usable for ECUs without permanent power supply inside. Depending on the version, there is a power plug on the ECU side or an open cable end on the power cable:
-
For thin walled housings, use a through boring with 15.2 mm in the housing and mount the cable with a nut (not included) (SM-PE 9 Order number 52103210 from Lapp).
-
For wall thickness more than 4mm cut a thread into the housing.
If the CBAM305.1-2m2 is used, a 2 pin Erni connector (214011 or compatible) must be available on the ECU as counterpart for the UBatt connector.
|
Note |
|---|
|
It is recommended for safety reasons to connect the external permanent voltage and the switched voltage inside the ECU! |
|
Note |
|---|
|
For mounting the cable, cut a PG9 thread into the ECU housing. For thin walled housings use a nut SM-PE 9. It is available from Lapp (order number: 52103210). |
Mechanical Dimensions
CBAM305.1-0m6 Cable
CBAM305.1-2m2 Cable
Connectors
CBAM305.1-0m6 Cable
|
Connector |
Color |
Target |
|---|---|---|
|
CON1 |
Blue purple |
GBit Ethernet cable, e.g. CBE260 |
|
CON2 |
White |
FETK |
|
CON3 |
Black |
Permanent power supply, K70.1 cable |
|
CON4 |
Red |
FETK UBATT |
CBAM305.1-2m2 Cable
|
Connector |
Color |
Target |
|---|---|---|
|
CON1 |
Blue purple |
GBit Ethernet cable, e.g. CBE260 |
|
CON2 |
White |
FETK |
|
CON3 |
Black |
Permanent power supply, K70.1 cable |
|
CON4 |
Red |
2 pin ERNI power ECU connector |
Temperature Range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +125 °C |
Tightness
|
Condition |
IP Code |
|
PG9 screwing |
IP67 |
Order Information
|
Product |
Length |
Order Number |
|
CBAM305.1-0m6 |
0.6 m |
F 00K 109 297 |
|
CBAM305.1-2m2 |
2.2 m |
F 00K 112 338 |
