CON1: CBAM295 cable
Usage
BR_XETK ECU adapter and power supply cable for 100 MBit/s Automotive Ethernet and BR_XETKs with external power supply. Usable for ECUs without permanent power supply inside.
Mechanical dimension
|
Product |
Length A [mm] |
Length B [mm] |
|---|---|---|
|
CBAM295.1-0m6 |
400 |
160 |
|
CBAM295.1-1m8 |
1500 |
250 |
Tightness
|
Condition |
Degree of Protection |
|
M12 screwing |
IP67 |
|
CON1, CON4 (plugged) |
IP65 |
Mounting
The CBAM295.1 cable is passed through a pre-assembled M12 screw connection.
The shield is connected to the screw. For thin-walled housings, use a through boring with 12.2 mm in the housing and mount the cable with a nut. Cable delivery does not include the nut. The nut must be ordered separately by AGRO (AGRO order number 8000.12). For wall thickness more than 2.5 mm cut a thread into the housing.
The minimum bending radius for the cable is 20 mm.
Pin assignment
|
Connector |
Color |
Target |
|---|---|---|
|
CON1 |
Black |
Cable to Media Converter, e.g. CBEB120.1 |
|
CON2 |
White |
BR_XETK interface connector |
|
CON3 |
- |
Shield ECU housing |
|
CON4 |
Black |
Cable to connect permanent power supply, e.g. K70.1 |
|
CON5 |
Red wire |
BR_XETK UBATT pin |
Temperature range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +105 °C -40 °F to + 221 °F |
Order information
|
Product |
Length |
Order Number |
|
CBAM295.1-0m6 BR_XETK ECU Adapter and Power Supply Cable, pre-assembled into M12 screwing, shield on ECU housing, Lemo 1B PHA - MOLEX (2fc- 2fc) / Lemo 1B PHG - open wire (2fc-1c), 0m6 |
0.60 m |
F 00K 111 656 |
|
CBAM295.1-1m8 BR_XETK ECU Adapter and Power Supply Cable, pre-assembled into M12 screwing, shield on ECU housing, Lemo 1B PHA - MOLEX (2fc- 2fc) / Lemo 1B PHG - open wire (2fc-1c), 1m8 |
1.80 m |
F 00K 111 657 |
