CON1: CBAM290 cable
Usage
The CBAM290.1 cable is a 100 MBit/s Automotive Ethernet cable adapter for BR_XETKs. The cable is passed through a M10 screw connection, the shield is connected to the screw.
Tightness
|
Condition |
Degree of Protection |
|
M10 screwing |
IP67 |
|
CON1 (plugged) |
IP65 |
Mounting
For thin-walled housings, use a through boring with 10.2 mm in the housing and mount the cable with a nut. Cable delivery does not include the nut. The nut must be ordered separately by AGRO (AGRO order number 8000.10). For wall thickness more than 2.5 mm cut a thread into the housing.
The minimum bending radius for the cable is 16 mm.
Pin assignment
|
Connector |
Color |
Target |
|---|---|---|
|
CON1 |
Black |
Cable to Media Converter, e.g. CBEB120.1 |
|
CON2 |
White |
BR_XETK interface connector |
|
CON3 |
- |
Shield ECU housing |
Temperature range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +105 °C -40 °F to + 221 °F |
Order information
|
Product |
Length |
Order Number |
|
CBAM290.1 BR_XETK ECU Adapter Cable, preassembled into M10 screwing, shield on ECU Housing, Lemo 1B PHA - MOLEX (2fc-2fc), 0m60 |
0.60 m |
F 00K 111 117 |
