CBEB242 cable
Usage
Cable for connecting the Automotive Ethernet interface (AE) of an ES800 module to BR_XETKs.
|
Note |
|---|
|
The CBEB242.1 cable is designed for directly connecting BR_XETKs. For other areas of application, ETAS recommends the CBEB240.1 Automotive Ethernet cable. |
Assignment of the automotive ethernet channels to the cable sections
The CBEB242.1 cable consists of four identical cable sections [n], each mapped to an Automotive Ethernet channel [n] of the Automotive Ethernet interface (AE) and wired in accordance with the same pattern. Each of the cable section is equipped with a DSUB9 connector.
Labeling of the automotive ethernet channels and the cable sections
The cable sections are labeled [n]=1 to [n]=4 and are also marked with the color of the LEDs corresponding to the channels [n] at the AE connection of the module. The colors of the channels [n] at the AE connection of the module and the cable sections are identical.
|
ES800 module |
Color |
Automotive Ethernet channel ES882.1 |
Automotive Ethernet channel ES886.1 |
|---|---|---|---|
|
1 |
Purble |
AE1 |
AE1 |
|
2 |
Orange |
AE2 |
AE2 |
|
3 |
Green |
AE3 |
AE3 |
|
4 |
Blue |
- |
AE4 |
When using the CBEB242.1 cable at the AE interface of the module ES882.1 (three Automotive Ethernet channels), three of the four cable harnesses are used in accordance with the assignment in the table.
Assignment of the automotive ethernet signal to the DSUB9 connectors
The assignment of the connections of the DSUB9 connector of a cable section to the signals of an Automotive Ethernet channel [N] is represented in the table.
|
Pin |
Signal |
Meaning |
|
4 |
AE [n]+ |
Automotive Ethernet, channel [n], BI_DA+ |
|
5 |
AE [n]- |
Automotive Ethernet, channel [n], BI_DA- |
Temperature range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +85 °C -40 °F to + 185 °F |
Order information
|
Product |
Length |
Order Number |
|
Automotive Ethernet Splitter Cable 100 Mbit/s, Yamaichi YCP - 4x DSUB (8mc - 4x 9mc), 0m4 |
0.4 m |
F 00K 111 123 |
