CBEB240 cable
Usage
Cable for connecting the Automotive Ethernet interface (AE) of an ES800 module to BR_XETKs, ECUs with Automotive Ethernet interfaces or Ethernet-based vehicle buses.
Assignment of the automotive ethernet channels to the cable sections
The CBEB240.1 cable consists of four identical cable sections [n], each mapped to an Automotive Ethernet channel [n] of the Automotive Ethernet interface (AE) and wired in accordance with the same pattern. Each of the cable section is equipped with a LEMO connector.
Labeling of the automotive ethernet channels and the cable sections
The cable sections are labeled n=1 to n=4 and are also marked with the color of the LEDs corresponding to the channels [n] at the AE connection of the module. The colors of the channels [n] at the AE connection of the module and the cable sections are identical.
|
ES800 module |
Color |
Automotive Ethernet channel ES882.1 |
Automotive Ethernet channel ES886.1 |
|---|---|---|---|
|
1 |
Purble |
AE1 |
AE1 |
|
2 |
Orange |
AE2 |
AE2 |
|
3 |
Green |
AE3 |
AE3 |
|
4 |
Blue |
- |
AE4 |
When using the CBEB240.1 cable at the AE interface of the module ES882.1 (three Automotive Ethernet channels), three of the four cable sections are used in accordance with the assignment in the table.
Assignment of the automotive ethernet signal to the LEMO connectors
The assignment of the connections of the LEMO connector of a cable section to the signals of an Automotive Ethernet channel [N] is represented in the table.
|
Pin |
Signal |
Meaning |
|
1 |
AE [n]+ |
Automotive Ethernet, channel [n], BI_DA+ |
|
2 |
AE [n]- |
Automotive Ethernet, channel [n], BI_DA- |
Temperature range
|
Condition |
Temperature Range |
|
Operating temperature |
-40 °C to +85 °C -40 °F to + 185 °F |
Order information
|
Product |
Length |
Order Number |
|
CBEB240.1-0m4 Automotive Ethernet splitter cable 100 Mbit/s, Yamaichi YCP - 4x Lemo PHA 1B |
0.4 m |
F 00K 111 122 |
