CBEB121 cable
Usage
The CBEB121.1 cable is a 100 MBit/s Automotive Ethernet cable to connect a CBEB100.1 Media Converter with a BR_XETK cable adapter (e.g. CBAM290.1).
Pin assignment
|
Connector |
Target |
|---|---|
|
CON1 |
BR_XETK cable adapter |
|
CON2 |
CBEB100.1 Media Converter |
|
CON3 |
Power supply |
Mounting
Minimum cable bending radius: 16 mm.
Order information
|
Product |
Length |
Order Number |
|
CBEB121.1-3 100 Mbit/s Automotive Ethernet Interface Cable plus Power for CBEB100, Lemo 1B FGA -DSUB plus banana connector (2mc-9fc), 3 m |
3 m |
F 00K 111 113 |
|
CBEB121.1-5 100 Mbit/s Automotive Ethernet Interface Cable plus Power for CBEB100, Lemo 1B FGA - DSUB plus banana connector (2mc-9fc), 5 m |
5 m |
F 00K 111 114 |
