Status indicator

LED specification

There are three LEDs displaying the operating mode BR_XETK-S3.0:

LED State Definition
Red On BR_XETK-S3.0 is supplied with power and active (i.e., the ECU is switched on or the ETAS calibration and development system is connected and ready to communicate with the BR_XETK-S3.0)
Green Off The Working contains data and is accessible from INCA.
  Flashing

BR_XETK-S3.0 is in boot configuration mode.

  • measurement and calibration are not possible

  • BR_XETK-S3.0 update with HSP is required
  On

Power supply has dropped under selected threshold:

  • data retention of the calibration data manager in the ECU is no longer ensured

  • as soon as the BR_XETK-S3.0 switches on again, the ECU switches to the Reference Page.

Green LED stays lit until the calibration and development system downloads data into the calibration data memory. Otherwise switching to the Working Page is not possible.
Yellow Off BR_XETK-S3.0: no link to calibration system established.
  On 100 Mbit/s communication to calibration system established.
  Flashing Communication active.
