Adding ASCET, FMU, Simulink Models, TSim Plugin

NOTICE
Potential malicious code from external source For FMU, ASCET and TSiM model types, ASCMO-MOCA executes an external runnable during model evaluation. Make sure that the external runnable of the model comes from a trustworthy source.

NOTICE

Potential malicious code from external source

For FMU, ASCET and TSiM model types, ASCMO-MOCA executes an external runnable during model evaluation.

Make sure that the external runnable of the model comes from a trustworthy source.

You can add the following models to your MOCA project:

These models can then be used in the function.

Note
FMU models that use FMI 2.x or FMI 3.x are supported by ASCMO-MOCA. FMU models that use FMI 1 cannot be used.

Open the Models Step.
In the Models Step, click on Add Model and select Connect to ASCET Model / Connect to FMU Model / Connect to Simulink Model / Connect to TSim Plugin.

A new line with a default model name is added to the model list; additional options are displayed in the lower part of the Models Step. See also Models Step – ASCET Model Variant / Models Step – FMU Model Variant / Models Step – Simulink Model Variant / .
Optionally, use the Rename button to rename the model.
In the "ASCET-PSL Model" / "FMU Model" / "Simulink Model" / "TSim Plugin" field, enter or select (via the button) path and name of the model to be optimized.

Examples files are given:
- ASCET <installation>\Example\Moca\Torque_Ascet_Psl.dll
- FMU <installation>\Example\Moca\Torque_with_FMU.fmu
- Simulink <installation>\Example\Moca\Torque.mdl
- Simulink <installation>\Example\Moca\PID.slx
- TSim <installation>\Example\Moca\TorquePlugin.mexw64.
Map the Inputs, Parameters and Outputs.
(see Map ASCET parameters / Map FMU parameters / Map Simulink Parameters, Map ASCET Inputs / Map Simulink Inputs, and Map ASCET Outputs / Map Simulink Outputs)

Note
Using / in the Model Step after building the function has an impact on the order of arguments in the Function.
